Send Inquiry

Product Description

📦

Product Description

Characteristics:
RJ45 Connector with integrated transformer / common mode choke. Power over Ethernet up to 50 Watt and speeds up to 10 Gbit/s. Available in SMT, THT and THT with USB. Compliant with standards: IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at and upcoming IEE 802.3bt. HPLE products: Improved Common Mode Rejection due to additional NiZn cores.
RJ45 Connector Characteristics
📋

Specification

Item Value
Model Number RJ45 Filtered Connectors
Part Status Active
Connector Type RJ45
Applications-Lan Ethernet(PoE/Non_PoE)
Speed 10/100/1000/2.5G/5G/10G Base-T, AutoMDIX
Mounting Type Through Hole
Orientation 90° Angle (Right)
Termination Solder
Contact Finish Thickness 6.00µin (0.152µm)
LED Color Yellow/Green, Green/Yellow, Green&Yellow/Green&Yellow
Number of Cores per Jack 4/6/8/12
Shielding Shielded, Emi Finger
Number of Ports 2x1 2x2 2x4 2x6 2x8 Port
Features Board Guide
Tab Direction Down/Up
Contact Finish Gold
Configuration RX/TX T,C
Turns Ratio RX/TX 1CT:1CT
Operating Temperature 0°C ~ 70°C / -40°C ~ +85°C
🚚

Packing & Delivery

Package Details:
Package: Tray
Carton size: 32*30*31cm
G.W./carton: 8.5kg
Qty/carton: 1200pcs
SPQ: 50pcs
N.W/pcs: 0.007kg
Packing Details
🏢

Facility Display

❓

FAQ

What data speeds do your RJ45 Filtered Connectors support?
Our connectors are highly versatile, supporting speeds ranging from 10/100/1000 Base-T up to high-speed 2.5G, 5G, and 10G Ethernet applications with AutoMDIX support.
Are these connectors compatible with Power over Ethernet (PoE)?
Yes, our RJ45 connectors with integrated transformers are designed for PoE applications, supporting up to 50 Watts and compliant with IEEE 802.3af/at/bt standards.
What is the standard operating temperature for these components?
We offer two temperature grades: a standard commercial range of 0°C to 70°C and an industrial-grade range of -40°C to +85°C to suit various environmental needs.
Do the connectors come with integrated LED indicators?
Yes, multiple LED color configurations are available, including Yellow/Green, Green/Yellow, and bi-color options to meet your system status requirements.
What certifications do your products hold?
Our products are manufactured under strict quality controls and are compliant with UL, REACH, CE, and standards.
Can I purchase these in specific port configurations?
Absolutely. We provide various multi-port configurations including 2x1, 2x2, 2x4, 2x6, and 2x8 port layouts to accommodate different PCB designs.
